Product Information :

Name :
Coolant Pump ACP-BMF
Category :
  1. เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล
Sub - Category :
  1. 993 A-Ryung Coolant Pump
Brand :
Aryung
Model :
ACP-BMF Type
Product Type :
  1. สินค้า, ผลิตภัณฑ์
Short Description :
ACP-BMF DIVISION : Large-liquid TYPE TYPE : 1500BMF 2200BMF 3700BMF 5500BMF

Product Detail :

ACP-BMF TYPE




Coolant Pump



This type is multistage centrifugal pump and used high quantity flowing of oil for the large machine with high precise and efficiency. It is proper to make working part surface slick by flowing down and washing the chips with cooling fluid.

As the motor is separated from pump part, the high temperature of motor does not transfer directly to the pump, so the oil temperature keeps constantly.

ÆßÇÁ¼³Ä¡½Ã À̹°ÁúÀÇ È¥ÀÔÀ¸·Î ÀÎÇÑ ÈíÀÔÀúÇϸ¦ ¹æÁöÇϱâ À§ÇÏ¿© ÅÊÅ©ÀÇ ¹èÃâÃø°ú ÈíÀÔÃø »çÀÌ¿¡ °ÝÆÇÀ» ¼³Ä¡ÇÏ°í, ÆßÇÁ Casing°ú ÅÊÅ© ¹Ø¸é°ú´Â 40mmÀÌ»ó Æ´»õ¸¦ À¯ÁöÇÏ¿©¾ß ÇÑ´Ù.

The divider should be installed between inlet and outlet to protect reduction of suction power by mixing dust, and keep 40mm distance between pump casing and tank bottom.

When installed added pipe at inlet, the bottom casing should be submerged over 1 stage to avoid not sucking at first operation.

The special mechanical seal improves endurance of pump life.
