E-Catalog > Powder Clutch > PRC-C3 (One Shaft Type)

PAGE VIEW : 14,052

Product Information :

Name :
PRC-C3 (One Shaft Type)
Category :
  1. เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล
Sub - Category :
  1. Powder Clutch
Brand :
Pora
Model :
Model PRC-C3
Product Type :
  1. สินค้า, ผลิตภัณฑ์

Product Detail :




PRC-C3 (One Shaft Type)




You can use the Powder Brake/Clutch that has exellent magnetic force control in wide range of industrial machines sinse it is simple to attach and 100% compatible with international and food machines.



Model Torque
(Nm)		 Voltage
(DC V)		 Current
(A)		 Power
(W)		 Powder
Quantity
(g)		 Rev
Count
(rpm)		 Rate of Slip
Production
(W)		 Bearing
Specification		 Weight
(kg)
PRC-2.5C₃ 25 24 2.7 64.8 50 800 500 #6003/#6910 10.1

PRC-5C₃ 50 3.5 84 80 800 800 #6205/#6914 18.2

PRC-10C₃ 100 2.9 69.6 120 800 1500 #6205/#6014 35.7

PRC-20C₃ 200 3.7 88.8 200 500 2800 #6007/#6207/#6018 53.3

PRC-40C₃ 400 4.3 103.2 450 500 3700 #6007/#6207/#6018
